102B

5-44 plug to BNC plug low noise cable
5-44 plug to BNC plug low noise cable, designed for sensor testing, with a characteristic impedance of 50 ohms. The cable features a pure nickel wire core for stable transmission, with an outer diameter of 1.9mm and made of blue PFA material. It has a fine wire diameter and high wear resistance.
This cable is widely used in audio testing systems, connecting amplifiers, speakers, sensors, and other devices.

Specifications

Cable Length	1.5m、3m、6m、9m、12m，Custom Cable Length
Temperature Range	-60℃ - 200℃
Impedance	50Ω
Connector Type	5-44 Plug to BNC Plug
Strain Relief	Heat Shrink Tubing Formed, Black PE;PVC Molded Boot
Cable Specifications	Coaxial Cable, Inner Core of Silver Plated Copper Wire + PTFE Insulation + braided high shielding ≥95%, Cable Jacket: White PFA OD:1.9mm±0.05mm

Ordering Information

PN	Model	Description
730006-015	120B015	5-44 Plug to BNC Plug,cable jacket diameter 1.9mm,blue PFA low noise cable,high temperature resistance 250℃, length 1.5m
730006-030	120B030	5-44 Plug to BNC Plug,cable jacket diameter 1.9mm,blue PFA low noise cable,high temperature resistance 250℃, length 3.0m
730006-060	120B060	5-44 Plug to BNC Plug,cable jacket diameter 1.9mm,blue PFA low noise cable,high temperature resistance 250℃, length 6.0m
730006-090	120B090	5-44 Plug to BNC Plug,cable jacket diameter 1.9mm,blue PFA low noise cable,high temperature resistance 250℃, length 9.0m
730006-120	120B120	5-44 Plug to BNC Plug,cable jacket diameter 1.9mm,blue PFA low noise cable,high temperature resistance 250℃, length 12.0m
730006-000	120B	5-44 Plug to BNC Plug,cable jacket diameter 1.9mm,blue PFA low noise cable,high temperature resistance 250℃, Customizable length
