SK 516 Shaker

• Medium to large size, Air bearing support, Grating displacement sensing, R&D use

• SK 516 is a medium-to-low frequency vibration shaker that uses high-precision air bearings as supporting and guiding devices, with high guiding accuracy, which can greatly reduce lateral motion; Simultaneously using air as the lubricating medium results in minimal frictional resistance and minimizes friction noise to the greatest extent possible; It also uses magnetic levitation support technology, which serves as a support and buffering structure. Compared to traditional spring plate support structures, the system has higher linearity and longer service life; It also has a high-precision grating displacement sensor built-in, which can achieve closed-loop control of displacement signals and greatly improve displacement accuracy.

  SK 516 is suitable for various vibration experiments, such as calibration testing of acceleration sensors, vibration testing experiments of consumer products, etc. Paired with MegaSig PM 6682 acquisition card to achieve excellent testing results.
